OAuth is a method for authorization that allows access to third-party applications or services without requiring the sharing of usernames and passwords.

How OAuth 2.0 Works?

OAuth 2.0 is an authorization protocol designed to provide secure delegated access to resources without exposing user credentials to third-party applications.

Key Components:

• Resource Owner: The user who owns the data or resource.
• Client: The application requesting access to the user’s resource on behalf of the user (e.g., a web or mobile app).
• Resource Server: The server hosting the protected resources (e.g., an API).
• Authorization Server: The server that authenticates the user and issues access tokens. This may be the same as the Resource Server.

OAuth Flows (Grant Types):

OAuth 2.0 offers different authorization flows based on the type of application and security requirements.

1. Authorization Code Grant (Most Secure)

This is the most commonly used flow for server-side web applications.

Steps:

1. Client Requests Authorization: The client redirects the user to the authorization server with a request for permission to access the resource.
2. User Authorizes the Client: The user logs into the authorization server and consents to the requested access.
3. Authorization Code Issued: Upon approval, the authorization server redirects the user back to the client with an authorization code.
4. Client Exchanges Code for Access Token: The client securely exchanges the authorization code for an access token by sending a request to the authorization server.
5. Client Accesses Resource: The client uses the access token to request the resource from the Resource Server. ![[Pasted image 20241017145740.png]]

2. Implicit Grant (Less Secure)

Primarily used by single-page apps (SPAs) or public clients where keeping credentials secret is difficult.

Steps:

1. Client Requests Authorization: The client redirects the user to the authorization server.
2. User Authorizes: The user approves the request, and the authorization server redirects the user back with an access token.
3. Client Accesses Resource: The client immediately uses the access token to request resources.

This flow is considered less secure because the access token is exposed in the URL.

3. Client Credentials Grant

Used for machine-to-machine communication without user interaction.

Steps:

1. Client Requests Access Token: The client directly requests an access token by presenting its client ID and client secret to the authorization server.
2. Access Token Issued: If the credentials are valid, the authorization server issues an access token.
3. Client Accesses Resource: The client uses the access token to access the protected resource.

![[Pasted image 20241017150006.png]]

4. Password Grant (Deprecated)

Allows the client to use the user’s credentials (username and password) to directly request an access token.

Steps:

1. Client Sends Credentials: The client sends the user’s username and password to the authorization server.
2. Access Token Issued: The server validates the credentials and issues an access token.
3. Client Accesses Resource: The client uses the access token to request resources.

This method is not recommended due to security concerns, as it requires the user to share their credentials with the client.

5. Refresh Token

Allows the client to obtain a new access token without involving the user when the original token expires.

Steps:

1. Client Sends Refresh Token: The client sends a valid refresh token to the authorization server.
2. Access Token Issued: The server responds with a new access token.

Security Mechanisms in OAuth 2.0

OAuth 2.0 includes several security measures to protect data and prevent unauthorized access:

1. Access Token Expiration: Tokens have a limited lifespan to minimize the risk of misuse.
2. Scopes: Tokens include scopes that define the level of access to resources. This ensures the client only accesses what’s necessary.
3. Token Encryption: In some cases, access tokens are encrypted to prevent unauthorized inspection.
4. Authorization Code Exchange: In the authorization code flow, the token is not returned directly to the client. Instead, it’s exchanged securely using client credentials, reducing exposure.
5. PKCE (Proof Key for Code Exchange): An extension to OAuth 2.0 that adds an extra layer of security to public clients (like mobile apps) by mitigating the risk of code interception.

JWT (JSON Web Token) is a compact, URL-safe token used to represent claims between two parties. It allows for secure transmission of information, often used for authorization without sharing credentials like usernames or passwords.

JWT consists of three parts:

1. Header:
   • This contains metadata about the token, including the type (typically “JWT”) and the algorithm used for signing (e.g., HS256, RS256).
2. Payload:
   • The payload carries claims, which are pieces of data about the user or session, such as the user identity, roles, or expiration time (exp). This is the part where the user information is stored.
3. Signature:
   • The signature ensures the integrity of the token. It is created by combining the header and payload, hashing them, and then signing with a secret or private key. The signature is what protects the token from being tampered with.

How Verification Works:

• The signature is verified by the recipient (often the resource server) to ensure the JWT hasn’t been altered.
• If asymmetric algorithms (like RSA) are used:
  • The server signs the token with a private key.
  • The recipient (resource server) uses the public key to decode the signature and validate that the content (header and payload) has not been modified.
  • The hash from the header and payload is recalculated by the resource server, and if it matches the signature, the token is verified as valid.

Access Granting:

• Once the JWT is validated and confirmed to be untampered, the resource server (the application the user is trying to access) grants access based on the claims (e.g., user identity, permissions) in the payload.
